Cylindrical grinder

Structural Features/STRUCTURAL FEATURES The horizontal feed of the grinding wheel rack is driven by hydraulic pressure to achieve micro automatic periodic feed and rapid advance and retreat, and can also be achieved by hand wheel for coarse and fine feed.

The M1350, M1450, M1363 series workbenches and grinding wheel racks use static pressure guide rails for smooth low-speed movement.
The M1350, M1450, and M1363 series grinding wheel holders adopt high rigidity dynamic and static pressure spindles, with high rotation accuracy and good rigidity.
The headband adopts a frequency converter to achieve stepless speed regulation. The universal headstock can be adjusted at any angle within 90 degrees counterclockwise to adapt to the chuck grinding of inner and outer conical workpieces.
